Products - Thermal Camera - FI640
 |
HD thermal camera The FI640 thermal camera is now also available with new technology and is based on a fully transformed platform. This high resolution and high performance, fixed IR camera offers capabilities that far exceed any IR camera on the market today. The 640 x 480 UFPA detector features a small pixel pitch of only 17 µm and detects temperature differences as small as 0.03 ºC. |
||||||
 |
According to system design, hardware design and software design, it realized clear image, quick-response, accurate temperature. As a new generation thermal camera, FI640 have many innovative features, include improved detail reproduction and better image quality. We believe FI640 can be used in many segments | ||||||
 |
|
|
|||||
 |
|||||||
Specifiaction
Detector Data |
|||
| Detector type | Uncooled Focal Plane Array | ||
| Resolution | 640×480 Pixels | ||
| Pitch | 17 μm | ||
| Spectral range | 8–14 μm | ||
| Standard lens | 23 × 17 / 40cm | ||
| Sensitivity/NETD | < 0.03°C @ +30°C / 30 mK | ||
| Spatial resolution | 0.6 mrad (IFOV)* | ||
| Frequency | 50Hz | ||
| Focus | Motor | ||
Measurement |
|||
| Temp range | –20 ~ +150°C and 0 ~ +600°C | ||
| Accuracy | ±2°C or ±2% of reading | ||
| NUC | Auto/Manual | ||
| Captured | Sequence and picture and file | ||
| Marker | 12 shapes with max./min./average | ||
| Correction | Transmission, Optics, Reflected, Lens | ||
| Isotherms | Yes | ||
| Auto Snap | Yes | ||
| Curve | Yes | ||
| Alarm | Yes | ||
| Comments | Date/time, temperature units °C/°F/K, language, scale | ||
| ZOOM | Continuous zooming on images | ||
Communication Interface |
|||
| Ethernet | RJ-45 | ||
| Digital input/output | Yes | ||
| Video Out | NTSC/PAL, Composite video | ||
| USB | Option | ||
Power Source |
|||
| Power Supply | 12 - 30V | ||
| Connector type | Phoenix-Style Connector | ||
| Power Consumption | 15W Typical | ||
Environmental |
|||
| Operating Temp | -15°C to 50°C 90% | ||
| Storage Temp | -40°C to 70°C 90% | ||
| Protection | IP 54 (IEC60529) | ||
| Shock | 30G (IEC60068-2-27) | ||
| Vibration | 3G (IEC60068-2-6) | ||
Physical Characteristics |
|||
| Size ( W × H × L ) | 85 mm x 85 mm x 220 mm | ||
| Weight | 1 kg | ||
| Mounting | UNC ¼"-20 | ||
Accessories |
|||
| Standard | - Carrying case - Lens Cap - CD-ROM(Software, Manual) - Packing List - Ethernet™ cable - Power cable - Power supply - Quickstart |
||
 |
 |
 |
|||
